• Air conditioning, dual-zone manual climate control with individual climate settings for driver and right-front passenger
• Audio system feature, speaker system (Includes 4 speakers on Regular Cab and 6 speakers on Extended and Crew Cab models.)
• Audio system, AM/FM stereo with CD player, seek-and-scan, digital clock, auto-tone control, Radio Data System (RDS) and speed-compensated volume (Upgradeable to (UC6) AM/FM stereo with 6-disc in-dash CD changer.)
• Cigarette lighter, on instrument panel
• Coat hook, driver-side rear (Also includes passenger-side coat hook on Extended and Crew Cab models.)
• Console, overhead mini with map lights
• Cruise control, electronic with set and resume speed
• Cup holders, front (Also includes rear cupholders on Extended and Crew Cab models)
• Defogger, rear-window electric (Not available with (A28) sliding rear window.)
• Door locks, power
• Driver Information Center that monitors numerous different systems depending on vehicle equipment
• Lighting, interior with dome and reading lights, backlit instrument panel switches and door handle-activated illuminated entry
• Mirror, inside rearview auto-dimming with 8-point compass and outside temperature display
• Power outlets, 2 auxiliary instrument panel-mounted with covers, 12-volt
• Remote Keyless Entry, with 2 transmitters, panic button and content theft alarm
• Seat trim, Custom Cloth
• Steering wheel, leather-wrapped, Black with theft-deterrent locking feature
• Theft-deterrent system, vehicle, PASSlock II
• Visors, driver and front passenger, padded with cloth trim, extenders, pocket on driver-side and vanity mirror on passenger-side, Shale-colored
• Warning tones, headlamp on, key-in-ignition, driver and passenger buckle up reminder and turn signal on
• Windows, power with driver and front passenger Express-Down

• Alternator, 105 amps (Not available with (VYU) Snow Plow Prep Package.)
• Brakes, 4-wheel antilock, 4-wheel disc
• Exhaust, aluminized stainless-steel muffler and tailpipe
• Frame, hydroformed ladder-type
• Rear wheel drive
• Recovery hooks, front, frame-mounted
• Steering, power
• Suspension Package, Handling/Trailering, heavy-duty, includes 36 mm piston monotube shocks
• Suspension, front independent with torsion bar and stabilizer bar
• Suspension, rear 3-stage springs
• Tire carrier, outside spare, winch-type mounted under frame at rear
• Tools, mechanical jack and wheel wrench located in back of cab

• Air bags, frontal, driver and right-front passenger (Regular and Extended Cab models includes passenger-side deactivation switch. Never place a rear- facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. Always use safety belts and the correct child restraints for your childs age and size. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Brakes, 4-wheel antilock, 4-wheel disc
• Daytime Running Lamps, with automatic exterior lamp control

HEAVY-DUTY POWER PACKAGE

• includes (LBZ) Duramax 6.6L Turbo Diesel engine
• (MW7) Allison 1000 6-speed automatic transmission and (G80) heavy-duty rear locking differential

AUDIO SYSTEM, AM/FM STEREO WITH CD PLAYER

• seek-and-scan
• digital clock
• auto-tone control
• Radio Data System (RDS) and speed-compensated volume (STD)

ENGINE, DURAMAX 6.6L TURBO DIESEL V8

• (360 hp [268.0 kW] @ 3200 rpm
• 650 lb-ft of torque [881.0 N-m] @ 1600 rpm) Includes (TQ3) heavy-duty dual
• 770 cold-cranking-amp batteries
• (KG3) 145-amp alternator
• (K47) high capacity air cleaner and (K05) engine block heater.

TIRES, LT215/85R16E ON-/OFF-ROAD, BLACKWALL

• (Includes 7 tires with (E63) Fleetside pickup box. Includes 6 tires with (ZW9) pickup box delete.

SEAT TRIM, CUSTOM CLOTH

• (STD)

TIRE, SPARE LT215/85R16E ON-/OFF-ROAD, BLACKWALL

• located at rear underbody of vehicle

LT1 PREFERRED EQUIPMENT GROUP

• Includes Standard Equipment

TRAILERING EQUIPMENT, HEAVY-DUTY

• includes trailering hitch platform
• 7-wire harness (harness includes wires for: park lamps
• backup lamps
• right turn
• left turn
• electric brake lead
• battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector
• instrument panel jumper wiring harness for electric trailer brake controller
• and 1-way sealed connector for center high-mounted stop/brake lamp and (K47) high-capacity air cleaner

SEATS, FRONT 40/20/40 SPLIT-BENCH, 3-PASSENGER DRIVER AND FRONT PASSENGER MANUAL RECLINING

• center fold-down armrest with storage
• adjustable outboard head restraints and storage pockets on Extended Cab models (STD)

XM SATELLITE RADIO

• With a wide variety of programming
• XM has something to excite any driver. Whether you want to be entertained or informed
• to laugh
• think
• or sing
• XM has the perfect channel for you - coast-to-coast
• and n digital-quality sound. 3 trial months-no obligation

TRAILERING WIRING PROVISIONS, FOR CAMPER, FIFTH WHEEL & GOOSENECK TRAILER

• includes additional 8-way wiring harness routed to front of pickup box and added 7-way sealed connector for the trailer harness

BATTERY, HEAVY-DUTY DUAL 770 COLD-CRANKING AMPS, MAINTENANCE-FREE

• with rundown protection and retained accessory power

AIR CLEANER, HIGH-CAPACITY

• (Included with (LBZ) Duramax 6.6L Turbo Diesel V8 engine
• (Z82) heavy-duty trailering equipment or (VYU) Snow Plow Prep Package.)

GVWR, 11,400 LBS (5171 kg)

• with dual rear wheels (STD)

TRANSMISSION, ALLISON 1000 6-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED WITH OVERDRIVE, ELECTRONIC ENGINE GRADE BRAKING AND TOW/HAUL MODE

• Includes (KNP) external transmission oil cooler

ENGINE BLOCK HEATER

• (Included with (LBZ) Duramax 6.6L Turbo Diesel V8 engine.)

PAINT, SOLID

• (STD)

MIRRORS, OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL CAMPER MANUAL-FOLDING AND EXTENSION

• integrated turn signal indicators and lower convex spotter glass (convex glass is not heated)

• HEAVY-DUTY POWER PACKAGE includes (LBZ) Duramax 6.6L Turbo Diesel engine (MW7) Allison 1000 6-speed automatic transmission and (G80) heavy-duty rear locking differential
• AUDIO SYSTEM AM/FM STEREO WITH CD PLAYER seek-and-scan digital clock auto-tone control Radio Data System (RDS) and speed-compensated volume (STD)
• SEAT ADJUSTER DRIVER 6-WAY POWER
• COOLING AUXILIARY EXTERNAL TRANSMISSION OIL COOLER HEAVY-DUTY AIR-TO-OIL
• ENGINE DURAMAX 6.6L TURBO DIESEL V8 (360 hp [268.0 kW] @ 3200 rpm 650 lb-ft of torque [881.0 N-m] @ 1600 rpm) Includes (TQ3) heavy-duty dual 770 cold-cranking-amp batteries (KG3) 145-amp alternator (K47) high capacity air cleaner and (K05) engine block heater.
• REAR AXLE 3.73 RATIO
• TIRES LT215/85R16E ON-/OFF-ROAD BLACKWALL (Includes 7 tires with (E63) Fleetside pickup box. Includes 6 tires with (ZW9) pickup box delete.
• STEERING WHEEL CONTROLS MOUNTED AUDIO AND DRIVER INFORMATION CENTER CONTROLS
• SEAT TRIM CUSTOM CLOTH (STD)
• TIRE SPARE LT215/85R16E ON-/OFF-ROAD BLACKWALL located at rear underbody of vehicle
• LT1 PREFERRED EQUIPMENT GROUP Includes Standard Equipment
• DIFFERENTIAL HEAVY-DUTY AUTOMATIC LOCKING REAR
• TRAILERING EQUIPMENT HEAVY-DUTY includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp and (K47) high-capacity air cleaner
• SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER DRIVER AND FRONT PASSENGER MANUAL RECLINING center fold-down armrest with storage adjustable outboard head restraints and storage pockets on Extended Cab models (STD)
• XM SATELLITE RADIO (subscription required)
• TRAILERING WIRING PROVISIONS FOR CAMPER FIFTH WHEEL & GOOSENECK TRAILER includes additional 8-way wiring harness routed to front of pickup box and added 7-way sealed connector for the trailer harness
• BATTERY HEAVY-DUTY DUAL 770 COLD-CRANKING AMPS MAINTENANCE-FREE with rundown protection and retained accessory power
• AIR CLEANER HIGH-CAPACITY (Included with (LBZ) Duramax 6.6L Turbo Diesel V8 engine (Z82) heavy-duty trailering equipment or (VYU) Snow Plow Prep Package.)
• GVWR 11 400 LBS (5171 kg) with dual rear wheels (STD)
• TRANSMISSION ALLISON 1000 6-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED WITH OVERDRIVE ELECTRONIC ENGINE GRADE BRAKING AND TOW/HAUL MODE Includes (KNP) external transmission oil cooler
• ENGINE BLOCK HEATER (Included with (LBZ) Duramax 6.6L Turbo Diesel V8 engine.)
• PAINT SOLID (STD)
• MIRRORS OUTSIDE HEATED POWER-ADJUSTABLE VERTICAL CAMPER MANUAL-FOLDING AND EXTENSION integrated turn signal indicators and lower convex spotter glass (convex glass is not heated)
• Rear Wheel Drive
• Tow Hooks
• Dual Rear Wheels
• Dual Rear Wheels
• Dual Rear Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Dual Rear Wheels
• Steel Wheels
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Automatic Headlights
• Daytime Running Lights
• Automatic Headlights
• Heated Mirrors
• Power Mirror(s)
• Privacy Glass
• Intermittent Wipers
• Split Bench Seat
• Cloth Seats
• Pass-Through Rear Seat
• Rear Bench Seat
• Floor Mats
• Adjustable Steering Wheel
• Leather Steering Wheel
• Immobilizer
• Power Windows
• Power Door Locks
• Security System
• Keyless Entry
• Power Door Locks
• Cruise Control
• Multi-Zone A/C
• A/C
• Rear Defrost
• AM/FM Stereo
• CD Player
• Power Outlet
• Auto-Dimming Rearview Mirror
• Passenger Vanity Mirror
• Front Reading Lamps
• Front Reading Lamps
• ABS
• 4-Wheel Disc Brakes
• Driver Air Bag
• Passenger Air Bag
• Daytime Running Lights
• Automatic Headlights

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Cold Cranking Amps @ 0° F (2nd): 770
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 16.4
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4670
• Gross Axle Wt Rating - Rear (lbs): 8550
• Curb Weight - Front (lbs): 3196
• Curb Weight - Rear (lbs): 2858
• Gross Vehicle Weight Rating Cap (lbs): 11400
• Gross Combined Wt Rating (lbs): 23500
• Gross Combined Wt Rating (lbs): 16000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 12000
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 9500
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1500
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1425
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 16400
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 9500
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 3500
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 2375
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 3-Stage Spring
• Spring Capacity - Front (lbs): 4800
• Spring Capacity - Rear (lbs): 8600
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 9200
• Axle Ratio (:1) - Rear: 3.73
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.25
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 1.2
• Tires
• Front Tire Order Code: XEF
• Front Tire Order Code: XYK
• Rear Tire Order Code: XEF
• Rear Tire Order Code: XYK
• Spare Tire Order Code: XEF
• Spare Tire Order Code: XYK
• Front Tire Size: LT215/85R16
• Rear Tire Size: LT215/85R16
• Spare Tire Size: LT215/85R16
• Front Tire Capacity (lbs): 2335
• Rear Tire Capacity (lbs): 2150
• Spare Tire Capacity (lbs): 2335
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 53.5
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 34
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 167.0
• Length, Overall w/o rear bumper (in): 258.5
• Width, Max w/o mirrors (in): 96.1
• Height, Overall (in): 77.3
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 52.2
• Front Bumper to Back of Cab (in): 148.1
• Cab to Axle (in): 55.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): 35.2
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 9.1
• Ground Clearance, Rear (in): 12.1
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 97.6
• Cargo Box Width @ Top, Rear (in): 61.9
• Cargo Box Width @ Floor (in): 64.8
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 61.9
• Cargo Volume (ft³): 73.9
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 39.0
• Second Leg Room (in): 39.1
• Second Shoulder Room (in): 65.1
• Second Hip Room (in): 62.9
• Summary
• Vehicle Name: Chevrolet Silverado 3500 Classic
• Body Style: Crew Cab 8' Fleetside
• Body Code: E63
