• Assist handle, front passenger (Also includes rear outboard passenger assist handle on Extended and Crew Cab Models.)
• Cigarette lighter, on instrument panel
• Coat hook, driver side (Also includes passenger side coat hook on Extended and Crew Cab Models.)
• Cupholders, front (Also includes rear cupholders on Extended and Crew Cab Models)
• Door trim, side reflectors
• Headliner, Shale-colored cloth, with matching retainer moldings
• Lighting, dome lamp, reading, courtesy, illuminated entry feature, backlit instrument panel switches and door handle-activated illuminated entry
• Mirror, inside rearview, manual day/night
• Power outlets, auxiliary, covered, 2 dash-mounted, 12-volt
• Seats, front 40/20/40 split-bench, 3-passenger with outboard head restraints and manual recliners
• Seats, rear bench, folding, 3-passenger (includes top tethers and lower anchors for child seat) (Not available with Regular Cab Models)
• Sound system feature, 4-speakers
• Steering wheel, steel sleeve, includes theft-deterrent locking feature
• Theft-deterrent system, PASSlock II
• Visors, padded, Shale-colored, driver and passenger side with cloth trim, extenders, pocket on driver side and vanity mirror on passenger side

• Alternator, 105 amps
• Brakes, 4-wheel antilock, 4-wheel disc
• Exhaust, aluminized stainless-steel muffler and tailpipe
• Frame, ladder-type
• Rear axle, 4.10 ratio
• Rear wheel drive
• Steering, power
• Suspension Package, Handling/Trailering, heavy-duty
• Suspension, front, independent torsion bar, and stabilizer bar
• Suspension, rear, semi-elliptic 2-stage multi-leaf springs
• Tire carrier, outside spare, winch-type mounted under frame at rear
• Tools, mechanical jack and wheel wrench, spare tire assist hook, floor-mounted in back of cab
• Wheels, 4 - 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug steel, painted, includes painted center caps and steel spare

• Brakes, 4-wheel antilock, 4-wheel disc
• Daytime running lamps, includes automatic exterior lamp control

TIRES, LT245/75R16E, ALL-SEASON, BLACKWALL

• (STD)

ENGINE, VORTEC 6000 V8 SFI

• (300 HP [223.8 kW] @ 4400 rpm
• 360 lb.-ft. [486.6 N-m] @ 4000 rpm) (STD)

LICENSE PLATE BRACKET, FRONT

• (will be forced on orders with ship-to states that require a front license plate)

SOUND SYSTEM, ETR AM/FM STEREO WITH CD PLAYER,

• includes seek-and-scan
• digital clock
• auto-tone control
• speed-compensated volume and Radio Data System (RDS)

SEATS, FRONT 40/20/40 SPLIT-BENCH, 3-PASSENGER WITH OUTBOARD HEAD RESTRAINTS AND MANUAL RECLINERS

• (STD)

GLASS, SOLAR-RAY DEEP TINTED

• (all windows except light tinted glass on windshield)

CRUISE CONTROL, ELECTRONIC WITH SET AND RESUME SPEED,

• includes telltale in instrument panel cluster

AIR CLEANER, HIGH-CAPACITY

• (Included with (LLY) Engine
• Duramax 6600 Turbo Diesel V8
• (Z82) Trailering equipment
• heavy-duty and (VYU) Snow Plow Prep Package)

SEATS, FRONT 40/20/40 SPLIT-BENCH, 3-PASSENGER, DRIVER AND PASSENGER MANUAL RECLINING

• center fold-down armrest with storage
• adjustable outboard head restraints and storage pockets on Extended and Crew Cab Models

TRAILERING EQUIPMENT, HEAVY-DUTY,

• includes trailering hitch platform
• 7-wire harness (harness includes wires for: park lamps
• backup lamps
• right turn
• left turn
• electric brake lead
• battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector
• 7-way to 4-way trailer adapter
• instrument panel jumper wiring harness for electric trailer brake controller
• and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner
• high capacity

TRANSMISSION, 4-SPEED AUTOMATIC, HEAVY-DUTY, ELECTRONICALLY CONTROLLED WITH OVERDRIVE, TOW/HAUL MODE

• and (KNP) Cooling
• external transmission oil cooler (STD)

PAINT, SOLID

• (STD)

WORK TRUCK PREFERRED EQUIPMENT GROUP,

• includes standard equipment

SEAT TRIM, VINYL

• (STD)

• TIRES LT245/75R16E ALL-SEASON BLACKWALL (STD)
• ENGINE VORTEC 6000 V8 SFI (300 HP [223.8 kW] @ 4400 rpm 360 lb.-ft. [486.6 N-m] @ 4000 rpm) (STD)
• LICENSE PLATE BRACKET FRONT (will be forced on orders with ship-to states that require a front license plate)
• REGULAR PRODUCTION ACCESSORY UNDERSEAT STORAGE REAR LOCKABLE.
• REAR AXLE 4.10 RATIO
• SOUND SYSTEM ETR AM/FM STEREO WITH CD PLAYER includes seek-and-scan digital clock auto-tone control speed-compensated volume and Radio Data System (RDS)
• SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER WITH OUTBOARD HEAD RESTRAINTS AND MANUAL RECLINERS (STD)
• GLASS SOLAR-RAY DEEP TINTED (all windows except light tinted glass on windshield)
• SPARE TIRE LOCK
• CRUISE CONTROL ELECTRONIC WITH SET AND RESUME SPEED includes telltale in instrument panel cluster
• AIR CLEANER HIGH-CAPACITY (Included with (LLY) Engine Duramax 6600 Turbo Diesel V8 (Z82) Trailering equipment heavy-duty and (VYU) Snow Plow Prep Package)
• RECOVERY HOOKS 2 FRONT FRAME-MOUNTED
• SEATS FRONT 40/20/40 SPLIT-BENCH 3-PASSENGER DRIVER AND PASSENGER MANUAL RECLINING center fold-down armrest with storage adjustable outboard head restraints and storage pockets on Extended and Crew Cab Models
• COOLING EXTERNAL TRANSMISSION OIL COOLER AUXILIARY HEAVY-DUTY AIR-TO-OIL
• TRAILERING EQUIPMENT HEAVY-DUTY includes trailering hitch platform 7-wire harness (harness includes wires for: park lamps backup lamps right turn left turn electric brake lead battery and ground) with independent fused trailering circuits mated to a 7-way sealed connector 7-way to 4-way trailer adapter instrument panel jumper wiring harness for electric trailer brake controller and 1-way sealed connector for center high-mounted stop/brake lamp. Also includes (K47) Air cleaner high capacity
• TRANSMISSION 4-SPEED AUTOMATIC HEAVY-DUTY ELECTRONICALLY CONTROLLED WITH OVERDRIVE TOW/HAUL MODE and (KNP) Cooling external transmission oil cooler (STD)
• PAINT SOLID (STD)
• DIFFERENTIAL LOCKING HEAVY-DUTY REAR
• WORK TRUCK PREFERRED EQUIPMENT GROUP includes standard equipment
• SEAT TRIM VINYL (STD)
• Rear Wheel Drive
• Tires - Front All-Season
• Tires - Rear All-Season
• Conventional Spare Tire
• Steel Wheels
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Automatic Headlights
• Daytime Running Lights
• Automatic Headlights
• Intermittent Wipers
• Vinyl Seats
• Split Bench Seat
• Rear Bench Seat
• Adjustable Steering Wheel
• Immobilizer
• Multi-Zone A/C
• A/C
• AM/FM Stereo
• Power Outlet
• Passenger Vanity Mirror
• Front Reading Lamps
• ABS
• 4-Wheel Disc Brakes
• Driver Air Bag
• Passenger Air Bag
• Daytime Running Lights
• Automatic Headlights

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 600
• Maximum Alternator Capacity (amps): 105
• Cooling System
• Total Cooling System Capacity (qts): 13.32
• Total Cooling System Capacity (qts): 16.36
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 4410
• Gross Axle Wt Rating - Rear (lbs): 6084
• Curb Weight - Front (lbs): 2973
• Curb Weight - Rear (lbs): 2283
• Gross Vehicle Weight Rating Cap (lbs): 9200
• Gross Combined Wt Rating (lbs): 16000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 10300
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1030
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 10300
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 1545
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 4500
• Spring Capacity - Rear (lbs): 6084
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 4800
• Axle Capacity - Rear (lbs): 6900
• Axle Ratio (:1) - Rear: 4.10
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): 1.42
• Brakes
• Brake Type: Pwr
• Brake ABS System: Four-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.8 x 1.5
• Rear Brake Rotor Diam x Thickness (in): 13 x 1.1
• Tires
• Front Tire Order Code: QIZ
• Rear Tire Order Code: QIZ
• Spare Tire Order Code: QIZ
• Front Tire Size: LT245/75R16
• Rear Tire Size: LT245/75R16
• Spare Tire Size: LT245/75R16
• Front Tire Capacity (lbs): 2205
• Rear Tire Capacity (lbs): 3042
• Spare Tire Capacity (lbs): 2205
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x 6.5
• Rear Wheel Size (in): 16 x 6.5
• Spare Wheel Size (in): 16 x 6.5
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: 24.1
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 46.8
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 26
• Fuel Tank Location: LH
• Exterior Dimensions
• Wheelbase (in): 143.5
• Length, Overall w/o rear bumper (in): 227.7
• Width, Max w/o mirrors (in): 79.7
• Height, Overall (in): 76.2
• Overhang, Front (in): 37.0
• Overhang, Rear w/o bumper (in): 47.2
• Front Bumper to Back of Cab (in): 138.6
• Cab to Axle (in): 41.9
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 9.1
• Ground Clearance, Rear (in): 12.1
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 78.7
• Cargo Box Width @ Top, Rear (in): 61.9
• Cargo Box Width @ Floor (in): 64.8
• Cargo Box Width @ Wheelhousings (in): 50.0
• Cargo Box (Area) Height (in): 19.5
• Tailgate Width (in): 61.9
• Cargo Volume (ft³): 56.9
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.0
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.2
• Front Hip Room (in): 61.4
• Second Head Room (in): 38.4
• Second Leg Room (in): 33.7
• Second Shoulder Room (in): 66.3
• Second Hip Room (in): 61.5
• Summary
• Vehicle Name: GMC Sierra 2500HD
• Body Style: Ext Cab 6.5' Fleetside
• Body Code: E63
