• Air conditioning, rear auxiliary
• Air conditioning, tri-zone automatic climate control with individual climate settings for driver and right-front passenger
• Antenna, integral in rear quarter glass
• Armrests, driver and passenger doors, padded
• Assist handles, front passenger and second row outboard
• Audio system controls, rear with 2 headphone jacks (headphones not included), power outlet and controls for volume, station selection and media
• Audio system feature, Bose premium 9-speaker system with subwoofer in center console
• Audio system, AM/FM stereo with MP3 compatible 6-disc in-dash CD changer seek-and-scan, digital clock and auto-tone control (Not available with (PCJ) Sun, Entertainment and Destinations Package.)
• Coat hooks, driver- and passenger-side rear seat and cargo area
• Console, overhead mini with map lights (Includes controls for sunroof, power liftgate and power release second row seats when (CF5) power sunroof, (E61) power liftgate with liftglass and (ARS) second row power seat release is ordered.)
• Cruise control, electronic with set and resume speed
• Cup holders, driver and passenger-side in third row side trim
• Cup holders, in front seating area
• Cup holders, in rear of floor console
• Defogger, rear-window electric
• Door locks, power programmable with lockout protection
• Door trim, lights on the front doors and side reflectors on the rear doors
• Driver Information Center, full-functionality included
• Floor covering, color-keyed carpeting
• Floor mats, color-keyed carpeted first and second row, removable
• Heater, rear auxiliary with rear passenger heating ducts
• Lighting, interior with dome light, driver- and passenger-side door switch with delayed entry feature, cargo lights, door handle or Remote Keyless Entry-activated illuminated entry and map lights in front and second seat positions
• Mirror, inside rearview auto-dimming with 8-point compass and outside temperature display
• Pedals, power-adjustable for accelerator and brake
• Power outlets, 5 auxiliary, 12-volt, includes 2 on the instrument panel, 1 in the cargo area, 1 inside the center console and 1 at the back of the console.)
• Rear Parking Assist, Ultrasonic with rearview LED display and audible warning
• Remote vehicle starter system includes Remote Keyless Entry
• Seat adjuster, driver power
• Seat adjuster, front passenger power
• Seats, front bucket with leather-appointed seating, 10-way power driver and front passenger seat adjusters, including power lumbar control, heated seat cushion and seatbacks, 2-position driver memory, adjustable head restraints, storage pockets and floor console
• Steering wheel controls, mounted audio and cruise controls, includes Driver Information Center controls located on instrument panel
• Steering wheel, leather-wrapped
• Storage bin, behind driver-side rear quarter panel
• Theft-deterrent system, vehicle, PASS-Key III
• Tire Pressure Monitoring System (does not apply to spare tire)
• Tow/haul mode selector, button located at end of shift lever
• Visors, driver and front passenger illuminated vanity mirrors, padded with cloth trim, extends on rod, includes corner storage pockets on back of visors, Shale-colored
• Warning tones, headlamp on, key-in-ignition, driver and passenger buckle up reminder and turn signal on
• Windows, power with driver Express-Down and lockout features
• XM Satellite Radio (subscription required)

• Body, liftgate with liftglass, rear door system with rear-window wiper/washer
• Exhaust, aluminized stainless-steel muffler and tailpipe
• GVWR, 7200 lbs. (3266 kg) (Requires 2WD 1/2 ton models.)
• Rear wheel drive
• Steering, power
• Suspension, front coil-over-shock with stabilizer bar (1/2 ton models only.)
• Suspension, rear multi-link with coil springs (1/2 ton models only.)
• Tools, mechanical jack and wheel wrench, stored in rear quarter trim
• Trailering equipment, heavy-duty, includes trailering hitch platform, 7-wire harness with independent fused trailering circuits mated to a 7-way sealed connector and (VR4) 2" trailering receiver

• Air bags, dual-stage frontal, driver and right-front passenger with Passenger Sensing System (Always use safety belts and the correct child restraints for your childs age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Air bags, head curtain side-impact, first and second row outboard seating positions with rollover sensor, includes third row seating positions with (AS3) 3-passenger third row 50/50 split-bench seat or (AW2) 2-passenger third row 50/50 split-bench seat (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.
• LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats
• OnStar Equipped (subscription required)
• StabiliTrak, stability control system with Proactive Roll Avoidance

TIRES, P265/70R17 ALL-SEASON, BLACKWALL

• (STD)

PREFERRED PACKAGE

• includes (XA7) heated windshield washer fluid system
• (CE1) Rainsense front intermittent wipers and (E61) power liftgate with liftglass

SEATS, SECOND ROW 60/40 SPLIT-FOLDING BENCH

• with leather-appointed seating
• 3-passenger with center armrest and storage tray (STD)

AUDIO SYSTEM, AM/FM STEREO WITH MP3 COMPATIBLE 6-DISC IN-DASH CD CHANGER

• seek-and-scan
• digital clock and auto-tone control (STD)

SEATS, THIRD ROW 50/50 SPLIT-BENCH

• with vinyl
• 3-passenger
• removable
• all-belts-to-seat

SUSPENSION PACKAGE, PREMIUM SMOOTH RIDE

• (STD)

SLT PREFERRED EQUIPMENT GROUP

• Includes Standard Equipment

WHEELS, 4 - 17" X 7.5" (43.2 CM X 19.1 CM) BRIGHT ALUMINUM, SPORT

• (STD)

ENGINE, VORTEC 5.3L V8 SFI WITH ACTIVE FUEL MANAGEMENT

• (320 hp [238.6 kW] @ 5200 rpm
• 340 lb-ft of torque [459.0 N-m] @ 4200 rpm)
• iron block (STD)

SEATS, FRONT BUCKET

• with leather-appointed seating
• 10-way power driver and front passenger seat adjusters
• including power lumbar control
• heated seat cushion and seatbacks
• 2-position driver memory
• adjustable head restraints
• storage pockets and floor console (STD)

TRANSMISSION, 4-SPEED AUTOMATIC, ELECTRONICALLY CONTROLLED

• with overdrive and tow/haul mode (STD)

• TIRES P265/70R17 ALL-SEASON BLACKWALL (STD)
• LICENSE PLATE BRACKET FRONT
• PREFERRED PACKAGE includes (XA7) heated windshield washer fluid system (CE1) Rainsense front intermittent wipers and (E61) power liftgate with liftglass
• SEATS SECOND ROW 60/40 SPLIT-FOLDING BENCH with leather-appointed seating 3-passenger with center armrest and storage tray (STD)
• AUDIO SYSTEM AM/FM STEREO WITH MP3 COMPATIBLE 6-DISC IN-DASH CD CHANGER seek-and-scan digital clock and auto-tone control (STD)
• SEATS THIRD ROW 50/50 SPLIT-BENCH with vinyl 3-passenger removable all-belts-to-seat
• DIFFERENTIAL HEAVY-DUTY LOCKING REAR
• SILVER BIRCH METALLIC
• SUSPENSION PACKAGE PREMIUM SMOOTH RIDE (STD)
• SLT PREFERRED EQUIPMENT GROUP Includes Standard Equipment
• WHEELS 4 - 17" X 7.5" (43.2 CM X 19.1 CM) BRIGHT ALUMINUM SPORT (STD)
• ENGINE VORTEC 5.3L V8 SFI WITH ACTIVE FUEL MANAGEMENT (320 hp [238.6 kW] @ 5200 rpm 340 lb-ft of torque [459.0 N-m] @ 4200 rpm) iron block (STD)
• SEATS FRONT BUCKET with leather-appointed seating 10-way power driver and front passenger seat adjusters including power lumbar control heated seat cushion and seatbacks 2-position driver memory adjustable head restraints storage pockets and floor console (STD)
• TRANSMISSION 4-SPEED AUTOMATIC ELECTRONICALLY CONTROLLED with overdrive and tow/haul mode (STD)
• REAR AXLE 3.73 RATIO
• LIGHT TITANIUM ULTRASOFT LEATHER-APPOINTED SEAT TRIM
• Rear Wheel Drive
• Tow Hitch
• Power Steering
• Aluminum Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Heated Mirrors
• Power Mirror(s)
• Integrated Turn Signal Mirrors
• Power Folding Mirrors
• Fog Lamps
• Luggage Rack
• Tow Hooks
• Conventional Spare Tire
• Luggage Rack
• Running Boards/Side Steps
• Automatic Headlights
• Privacy Glass
• Intermittent Wipers
• Intermittent Wipers
• AM/FM Stereo
• CD Changer
• CD Player
• MP3 Capability
• Premium Sound System
• Rear Seat Audio Controls
• Power Outlet
• Satellite Radio
• Requires Subscription
• Power Driver Seat
• Power Passenger Seat
• Leather Seats
• Bucket Seats
• Heated Front Seat(s)
• Driver Adjustable Lumbar
• Passenger Adjustable Lumbar
• Seat Memory
• 3rd Row Seat
• Pass-Through Rear Seat
• Adjustable Pedals
• Rear Parking Aid
• Keyless Entry
• Power Door Locks
• Remote Engine Start
• Universal Garage Door Opener
• Climate Control
• Multi-Zone A/C
• A/C
• Rear A/C
• Floor Mats
• Power Driver Seat
• Power Passenger Seat
• Adjustable Steering Wheel
• Leather Steering Wheel
• Cruise Control
• Steering Wheel Audio Controls
• Tire Pressure Monitor
• Power Windows
• Power Door Locks
• Cruise Control
• A/C
• Rear A/C
• Rear Defrost
• Immobilizer
• Power Outlet
• Auto-Dimming Rearview Mirror
• Front Reading Lamps
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Driver Illuminated Vanity Mirror
• Passenger Illuminated Visor Mirror
• Front Reading Lamps
• Rear Reading Lamps
• Traction Control
• Stability Control
• ABS
• 4-Wheel Disc Brakes
• Telematics
• Navigation from Telematics
• Requires Subscription
• Driver Air Bag
• Passenger Air Bag
• Passenger Air Bag Sensor
• Front Head Air Bag
• Rear Head Air Bag

• Vehicle
• Rear Door Type: Liftgate
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 20
• Electrical
• Cold Cranking Amps @ 0° F (Primary): - TBD -
• Maximum Alternator Capacity (amps): 160
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3300
• Gross Axle Wt Rating - Rear (lbs): 4200
• Curb Weight - Front (lbs): 2769
• Curb Weight - Rear (lbs): 2683
• Gross Vehicle Weight Rating Cap (lbs): 7200
• Gross Combined Wt Rating (lbs): 13000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7100
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1065
• Suspension
• Suspension Type - Front: Coil springs
• Suspension Type - Rear: Coil springs
• Spring Capacity - Front (lbs): 3300
• Spring Capacity - Rear (lbs): 4200
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-floating
• Axle Capacity - Front (lbs): 3400
• Axle Capacity - Rear (lbs): 4200
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 46
• Shock Absorber Diameter - Rear (mm): 46
• Stabilizer Bar Diameter - Front (in): 1.41
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 13.0 x 1.18
• Rear Brake Rotor Diam x Thickness (in): 13.7 x 0.79
• Tires
• Front Tire Order Code: QAN
• Rear Tire Order Code: QAN
• Spare Tire Order Code: ZRS
• Front Tire Size: P265/70R17
• Rear Tire Size: P265/70R17
• Spare Tire Size: P265/70R17
• Front Tire Capacity (lbs): 2105
• Rear Tire Capacity (lbs): 2105
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 17.5
• Rear Wheel Size (in): 17 x 17.5
• Spare Wheel Size (in): 17 x - TBD -
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 17.75
• Steering Ratio (:1), At Lock: 17.75
• Turning Diameter - Curb to Curb (ft): 43.0
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 31
• Exterior Dimensions
• Wheelbase (in): 130.0
• Length, Overall w/rear bumper (in): 222.4
• Width, Max w/o mirrors (in): 79.1
• Height, Overall (in): 76.8
• Overhang, Front (in): - TBD -
• Overhang, Rear w/bumper (in): - TBD -
• Ground to Top of Load Floor (in): 31.8
• Ground Clearance, Front (in): 10.5
• Ground Clearance, Rear (in): 9.1
• Rear Door Opening Height (in): - TBD -
• Rear Door Opening Width (in): - TBD -
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Console (in): - TBD -
• Cargo Area Length @ Floor to Seat 1 (in): 101.8
• Cargo Area Length @ Floor to Seat 2 (in): 69.6
• Cargo Area Length @ Floor to Seat 3 (in): 35.6
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): - TBD -
• Cargo Box (Area) Height (in): 41.4
• Cargo Volume to Seat 1 (ft³): 137.4
• Cargo Volume to Seat 2 (ft³): 90.0
• Cargo Volume to Seat 3 (ft³): 45.8
• Interior Dimensions
• Passenger Capacity: 7
• Front Head Room (in): 41.1
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 65.3
• Front Hip Room (in): 64.4
• Second Head Room (in): 38.5
• Second Leg Room (in): 39.5
• Second Shoulder Room (in): 65.2
• Second Hip Room (in): 61.8
• Third Head Room (in): 38.10
• Third Leg Room (in): 34.9
• Third Shoulder Room (in): 64.7
• Third Hip Room (in): 49.4
• Summary
• Vehicle Name: GMC Yukon XL
• Body Style: 4 Door
• Body Code: E52
